Refrigerator / Ice Maker Water Inlet Valve

The W10881366 Water Inlet Valve regulates the supply of water to the refrigerator’s ice maker (or dispenser) by opening and closing its solenoid-controlled ports based on signals from the appliance’s control system. It ensures proper refill volume and prevents overfilling or leaks.

Key Features:

• Dual-solenoid design allowing independent control of ice maker fill and water dispenser (if applicable)

• Operates at standard 110–120 VAC with a low power coil (approximately 15 W)

• Durable valve body with reliable sealing diaphragms to resist leakage under normal line pressure

• Input connection: ¼-inch compression (or compatible inlet port); Output ports: 5⁄16-inch or compatible tubing

• Mounting bracket and standard OEM form factor for drop-in replacement

• Compatible with refrigerator and ice maker systems that list W10881366, W10217918, W10433501, or 2313644 as water inlet / ice maker valve part references
