Dryer Timer

The W11043389 Timer manages and sequences the electrical functions of a clothes dryer’s cycle. It controls when power is sent to the motor, heating element, and other subsystems, advancing through pre-set intervals (dry, cool down, etc.) as selected by the user.

Key Features:

• Mechanical/electrical cam timer with internal switching contacts

• Drives cycle advancement in step intervals matching control knob settings

• Multi-terminal configuration to route power to heater, motor, and ancillary circuits

• D-shaped or keyed shaft interface for reliable knob coupling

• Built for regular cycling under thermal and electrical loading conditions

• Compatible with many Whirlpool, Maytag, Kenmore, JennAir, Amana, Crosley, and related dryer models that specify part number W11043389 (or equivalent W10436308)
