CMP Surface Element Infinite Control Switch WP3149404, 5.2-6.6 Amps for Whirlpool/Maytag/Amana Range

CMP Surface Element Infinite Control Switch WP3149404, 5.2-6.6 Amps for Whirlpool/Maytag/Amana Range

SKU:WP3149404

Regular price $21.75 USD
Regular price Sale price $21.75 USD
Sale Sold out
Quantity

3149404CM Replacement Part

The WP3149404 is a control switch (often called an “infinite” or variable control switch) for a 6-inch surface burner on an electric range. It regulates heat by varying the power delivered to that particular surface element.

3149404CM Key Features:

Rated for 240 V operation with a current range of approximately 5.2 to 6.6 amps

Dual load terminals allowing connection to both the surface element and line input

Multiple setting detents for gradual heat levels (low through high)

Durable internal contacts built for repeated switching under load

Standard mounting and shaft dimensions for drop-in replacement

Compatible with many Whirlpool, Maytag, KitchenAid, JennAir, Amana, Inglis, and related electric range models that call for WP3149404 (or cross-reference part numbers 3149404, 310179, 311847, 311856)

Replaces the following parts: ER3149404, 3148951, ES9404, W10295576, WP3149404V, 3149404, WP3149404VP, 3149404VP, 311857, 311847, 311856, 314144, 310179, ES3149404
